NO.

Item

Specification

Unit

Remark

1

Max.swing over bedmm

Φ300

mm

2

Diameter of rotation on X axis platform

Φ130

mm

3

Max. machining rod diameter

Φ30

mm

4

Max. length of machined parts

100

mm

5

Maximum spindle speed

6000

r/min

6

Spindle drawing pipe through hole diameter

Φ31

mm

7

Main motor power

4.2

kw

Built-in spindle motor

8

max. drilling diameter

Φ10

mm

9

Maximum tap thread

M8

10

Turning tool shank size

16×16

mm

11

X-axis stroke

320

mm

12

Z-axis stroke

270

mm

13

Min. setting unit of X and Z aixs

0.001

mm

14

X/Z axis fast moving speed

20

m/min

15

Repeated positioning accuracy

≤0.002

mm

16

Cooling motor power

0.18

kW

17

Size

1390×1330×1720

mm

18

Weight

~1500

kg
